20 products
04 Cabrinha X:Series Foil Kits
K4FKWPX2V-124200
Regular price $1,169.00 Save $0.00X1240 kit includes: Wing X1240 / Stabilizer V200 / Fuselage 346MM / Screw Set / T-nut Train / Torx Tool
X1650 Kit includes: Wing X1650 / Stabilizer V230 / Fuselage 346MM / Screw Set / T-nut Train / Torx Tool
When we introduced the X-Series wings, we took Cabrinha’s foil program to a whole new level. Through working alongside SINTEF and the University of Norway where we were able to fully breakdown and simulate hydrofoil performance in the world's largest cavitation tank. From this we have been able to further evolve the X-Series into the industry’s leading all round hydrofoil. Early lift, but with a high top speed has been achieved, and through refined tip shape and profile, you are able to break the tips free, but still be ready to carve into your next turn.
- Loose and agile
- All round lean profile
- Refined tip shape
- Tapered fit
- Torsional Stiffness
- Medium AR
- PMI core
- Pre Preg construction
- Modular
- Optimal efficiency and maneuverability
- Flat center, to downward tips, for perfect balance between locked-in feel and agility
- Single molded components for minimal drag
- Full prepreg carbon construction
- PMI core for superior strength to weight ratio
- NEW hollow fuselage for lightweight performance
- NEW insulated mounting surfaces for Improved durability and longevity
- Helicoils for superior durability and eliminating corrosion
- X1240- 1240cm^2 WS 870mm, AR 6.10, Chord 190
- X1650- 1650 cm^2, WS 1010mm, AR 6.18, Chord 220
- V2 00 cm², WS-360, AR-6.48
- V230 cm², WS-400, AR-6.96
- Fuselage(M) 346mm
04 Cabrinha H-Series Foil Kits
K4FKWPH2V-130200
Regular price $1,339.00 Save $0.00Includes: Wing H1300 / Stabilizer V200 / Fuselage 345MM / Screw Set / T-nut Train / Torx Tool
Just when you thought a product couldn’t get better, the new H-Series MkII pushes into the future of foil design and sets a new benchmark for efficiency and performance. The design team have implemented new technology learnt from the collaboration with Sintef. Water testing in the biggest tank in Europe has refined the H-series tip shape to allow the tips to breach and re-enter without cavitation. This allows more progressive riding and radical turns, be it with a kite, wing or prone. The new leaner profile now boasts an increased speed range which helps entry into freestyle tricks or on the race field. It seamlessly pairs with any of Cabrinha’s V-series stabs and is part of the modular Cab Fusion system.
- Ultra Efficient Design
- Ultra Lean Profile
- Refined Tip Shape.
- Tapered Fit
- Increased Torsional Stiffness
- High Aspect Ratio
- Barrel Nut Secure Connection
- Pre Preg Carbon Construction
- Modular Design to work with Cab Fusion Products
- Optimal efficiency and maneuverability
- Flat center, to downward tips, for perfect balance between locked-in feel and agility
- Single molded components for minimal drag
- Full prepreg carbon construction
- PMI core for superior strength to weight ratio
- NEW hollow fuselage for lightweight performance
- NEW insulated mounting surfaces for Improved durability and longevity
- Helicoils for superior durability and eliminating corrosion
- H1300 - 1300c
m
², WS 1090, AR 9.14, Chord 150mm
- V 200 cm², WS-360, AR-6.48
- Fuselage(M) 346mm
Mkii H Series Front Wing
K3FWHFWNG070XXX
Regular price Sale price $799.00 Save $0.00Just when you thought a product couldn’t get better, the new H-Series MkII pushes into the future of foil design and sets a new benchmark for efficiency and performance. The design team have implemented new technology learnt from the collaboration with Sintef. Water testing in the biggest tank in Europe has refined the H-series tip shape to allow the tips to breach and re-enter without cavitation. This allows more progressive riding and radical turns, be it with a kite, wing or prone. The new leaner profile now boasts an increased speed range which helps entry into freestyle tricks or on the race field. It seamlessly pairs with any of Cabrinha’s V-series stabs and is part of the modular Cab Fusion system.
High aspect ratio, swept outline, Ultra lean efficient profile, moderate anhedral with flared tips.
- Ultra Efficient Design
- Ultra Lean Profile
- Refined Tip Shape.
- Tapered Fit
- Increased Torsional Stiffness
- High Aspect Ratio
- Barrel Nut Secure Connection
- Pre Preg Carbon Construction
- Modular Design to work with Cab Fusion Products
- H550- 550cm², WS 690, AR 9.52, Chord 110mm
- H700- 700cm², WS 815, AR 9.49, Chord 120mm
- H850- 850cm², WS 900, AR 9.53 Chord 130mm
- H1050- 1050cm², WS 1000, AR 9.52, Chord 140mm
- H1300 - 1300c m ², WS 1090, AR 9.14, Chord 150mm
Set includes:
Wing cover, 2 x m6x30mm, 1 x m6x15mm, m6 barrel nut, screws.
X SERIES MKII FRONT WINGS
K2FWXFWNG070XXX
Regular price Sale price $699.00 Save $0.00FREERIDE
DESIGN PROFILE
WING FEATURES
-
Loose and agile
-
All round lean profile
-
Refined tip shape
-
Tapered fit
-
Torsional Stiffness
-
Medium AR
-
PMI core
-
Pre Preg construction
-
Modular
- X700- 700cm^2, WS 640mm, AR 5.85, Chord 140
- X930- 930cm^2, WS 750mm, AR 6.05, Chord 165
- X1240- 1240cm^2 WS 870mm, AR 6.10, Chord 190
- X1650- 1650 cm^2, WS 1010mm, AR 6.18, Chord 220
- X2100- 2100 cm^2, WS 1150mm, AR 6.01, Chord 255
KEY FEATURES
LOOSE AND AGILE
Through refined profiles, moderate aspect ratio and an all new wingtip shape, the X-Series MKII is the ultimate foil for maneuverability, no matter the board or sport you do.
ALL ROUND LEAN PROFILE
The allround lean profile still maintains the forgiving low-end that the X-Series is known for, but now boasts an increased speed range.
FEELING TIPSY
The all new tip design allows you to be able to free the tips in a turn, but be confident that the foil will re-enter without cavitation. This is one specific area of research & testing undertaken at the SINTEF facility.
TAPERED FIT
The ergonomic tapered connection between the fuselage and mast provides the ultimate in rigidity, while still being easy to assemble and disassemble.
TORSIONAL STIFFNESS
Through the use of a PMI core and the layered Pre Preg carbon sheets, the X-Series MKII sets a new benchmark for hydrofoil torsional stiffness.
MEDIUM AR
The medium aspect ratio design allows for early lift and a stable forgiving ride.
BARREL NUT
Brass 'through bolt' adds torsional stiffness to the wing / mast connection point.
PRE PREG
Pre coated carbon sheets allow for an extremely accurate level of resin absorption. Combined with an exclusive interweave design that follows the shape and profile of the wings, you have unparalleled levels of torsional stiffness and reflex response.
MODULAR
The modularity of the CAB Fusion system allows you to seamlessly interchange between any of the X-Series and H-Series front wings and stabilizers.
H SERIES FRONT WINGS
K1PFFHEFW065XXX
Regular price $749.00 Sale price $449.40 Save $299.60
DESIGN PROFILE
Swept outline, Ultra lean efficient profile, moderate anhedral
WING FEATURES
- Loose and agile feel for superior maneuverability
- Ultra lean profile for wide speed range
- Integrated fuselage with tapered fit
- Incredible torsional stiffness
- Full prepreg carbon construction
- PMI core for superior strength to weight ratio
- Moderate anhedral for a more efficient lift platform
TECH SPECS
- H650- 650cm², WS 720, AR 7.9, Chord 125mm
- H800- 800cm², WS 900, AR 9.9, Chord 125mm
- H1000- 1000cm², WS 900, AR 8.1, Chord 155mm
- H1200- 1200cm², WS 900, AR 6.7, Chord 185mm
Set includes:
Front wing, wing covers.
null
Mkii Fusion Carbon Mast
K3FSMASTC074XXX
Regular price Sale price $999.00 Save $0.00The all-new Hollow Mast system is yet another example of the state of the art foil program from Cab Design Works. It nods to the critical & complete design approach of the team to view every foil component individually with a view to improve stiffness across the entire platform. It implements a bladder molded construction with strategic layering of carbon as far to the outside as possible. This culminates in our stiffest ever mast to front wing connection. This reduction in flex eliminates any lag in the turn and transfers energy while pumping seamlessly through to the front wing.
Superior Torsional and bend rigidity. Low weight and minimum drag.
- Optimized airfoil for low drag to stiffness ratio
- TE scallop for improved turning and efficiency
- Integrated high modulus mounting plate
- Bladder molded, hollow mast construction for superior skin compression, providing ultimate rigidity
- Premium high modulus prepreg carbon fiber construction
- Barrel Nut compatible(x-series MkII and H-series MKII)
- Tapered Fit
MKII ALLOY MAST
K2FSMASTA065XXX
Regular price Sale price $209.00 Save $0.00HIGH PERFORMANCE - DURABILITY
SIZES: 40 / 70 / 90 CM MAST
DESIGN PROFILE
FEATURES
-
Choice of fixed top plate or FQR (Foil Quick Release)
-
3-screw connection for superior rigidity
-
Aircraft grade extruded, anodized 6061-T6 aluminum
-
Precision tapered fuse-to-mast connection for optimal rigidity
-
Helicoil inserts minimizes corrosion and provides long lasting durability
KEY FEATURES
FOIL ERGONOMICS
The ergonomic tapered connection between the fuselage and mast provides the ultimate in rigidity, while still being easy to assemble and disassemble.
AIRCRAFT GRADE
Highest quality anodized 6061 Aluminum provides not only strength and rigidity, but also longevity in salt water conditions.
STRENGTH TO WEIGHT
Low drag design to maximize hydrodynamic efficiency
LOCKED-IN
'Locked-in' mast to fuselage connection giving an exceptional torsional stiffness.
HELICOIL INSERTS
Helicoil inserts prevent corrosion and wear.
MODULAR
The modularity of the CAB Fusion system allows you to seamlessly interchange between any of the X-Series and H-Series front wings and stabilizers.
BARREL NUT
Brass 'through bolt' adds torsional stiffness to the wing / mast connection point.
Mkii Fusion Fuselage
K3FSAFUSELRGXXX
Regular price Sale price $179.00 Save $0.00One of the smallest but most critical parts of the foil system is the Fuselage. Often overlooked, the Fuselage allows you to truly custom tune your setup based not only on the conditions but also the sport you do.
The new Hollow fuselage maintains the same stiffness of the previous version, but in a lightweight structure, giving you increased range and earlier take off and control.
Light, stiff and durable.
- NEW hollow fuselage for lightweight performance
- NEW insulated mounting surfaces for Improved durability and longevity
- Helicoils for superior durability and eliminating corrosion
- 3 sizes to tune your ride.
V SERIES REAR WING STABILIZERS
K2FWVSWNG180XXX
Regular price Sale price $219.00 Save $0.00HIGH ASPECT
SIZES: 180 / 230 / 285
DESIGN PROFILE
FEATURES
- Optimal efficiency and maneuverability
- Flat center, to downward tips, for perfect balance between locked-in feel and agility
- Single molded components for minimal drag
- Full prepreg carbon construction
- PMI core for superior strength to weight ratio
- 180 cm², WS-340, AR-6.42
- 230 cm², WS-400, AR-6.96
- 285 cm², WS-450, AR-7.11
X SERIES FRONT WING
K1PFFUSFW-095XXX
Regular price Sale price $599.00 Save $0.00HIGH PERFORMANCE - LIGHT WEIGHT
Sizes: X950 / X1300 / X1600 / X1950
DESIGN PROFILE
Swept LE, Straight TE, Lean draft forward profile, moderate anhedral.
WING FEATURES
- Loose and agile feel for superior maneuverability
- Optimal efficiency and lift
- Integrated fuselage with tapered fit
- Incredible torsional stiffness and minimum drag
- Full prepreg carbon construction
- EPS core for superior strength to weight ratio
- Moderate anhedral for a more efficient lift platform
- Draft forward profile for a forgiving ride and early predictable lift
TECH SPECS
- X950- 950cm^2, WS 630cm, AR 4.2, Vol 1.18L
- X1300- 1300cm^2, WS 780cm, AR 4.7, Vol 1.6L
- X1600- 1600cm^2 WS 900cm, AR 5.05, Vol 2L
- X1950- 1950 cm^2, WS 1000cm, AR 5.13, Vol 2.5L
Set includes:
Front wing, wing covers.
Sold Separately:
Your choice of Fusion base kit.
X SERIES REAR STABILIZER
K1PFFUSRW-022XXX
Regular price $209.00 Sale price $125.40 Save $83.60HIGH PERFORMANCE - LIGHT WEIGHT
Sizes: XS220 / XS300
The best part of the last 5 years has been the rise in hybrid development and crossover technology amongst sports. No where is this more evident than in foil boarding. The hydrofoil has become the common denominator in all of the surf and wind sports today.
Therefore, it reasons that its important to have a hydro wing-set capable of crossing between sporting genres with flawless performance and capability. Enter the X Series™ wings from Cabrinha. The design of the X Series™ recognizes and exploits the most important features needed in all hydrofoiling genres. Lift, efficiency and control are the three pillars that drive the X Series’ high performance and buttery smooth ride.
Through a combination of outlines and wing profiles the X series delivers a smooth lift and stable flight with precise turning and control.
The X Series’ efficiency is enhanced by our all new Cab Fusion mast and fuselage ecosystem. The Cab Fusion is a redesign from the bottom up to remove any unwanted ‘play’ in the system while streaming the connection between the wings and the fuselage. The resulting increase in stiffness and reduction in drag puts the X Series wings into an all new class of hydrofoils.
DESIGN PROFILE
Swept LE, Straight TE, Lean profile, minimal anhedral with downturned tips.
WING FEATURES
- Optimal efficiency and lift
- Flat center, to downward tips, for perfect balance between locked-in feel and agility
- Recessed design for minimal drag
- Full prepreg carbon construction
- EPS core for superior strength to weight ratio
TECH SPECS
- 220 cm^2. WS 370.AR 6.4
- 300cm^2. WS 430, AR 6.4
Set includes:
Stabilizer, wing covers, 2pcs m6 ss316 torx Ti coated screws
FUSION ALLOY MAST WITH HELICOIL
K1FAALMAS090XXX
Regular price $229.00 Sale price $137.40 Save $91.60HIGH PERFORMANCE - DURABILITY
SIZES: 40 / 70 / 90 CM MAST
The Fusion Alloy mast is constructed from extruded aircraft grade aluminium that result in an incredibly rigid & hydrodynamic structure. Helicoil inserts eliminate salt water corrosion around the screw connection points. It seamlessly integrates into all 9cm industry-standard foil boxes.
- Choice of fixed top plate or FQR (Foil Quick Release)
- 3-screw connection for superior rigidity
- Aircraft grade extruded, anodized 6061-T6 aluminum
- Precision tapered fuse-to-mast connection for optimal rigidity
- Helicoil inserts minimizes corrosion and provides long lasting durability
FUSION FORGED MAST PLATE SOCKET MKII
K2FSMPLSK000XXX
Regular price $169.00 Save $0.00DESIGN PROFILE
FEATURES
-
Precision CNC machined aircraft grade, anodized 6061-T6 aluminum
-
Incredible torsional stiffness
KEY FEATURES
AIRCRAFT GRADE
Highest quality anodized 6061 Aluminum provides not only strength and rigidity, but also longevity in salt water conditions.
LOW DRAG DESIGN TO MAXIMISE HYDRODYNAMIC EFFICIENCY
Highest quality anodized 6061 Aluminum provides not only strength and rigidity, but also longevity in salt water conditions.
FOIL ERGONOMICS
The ergonomic tapered connection between the fuselage and mast provides the ultimate in rigidity, while still being easy to assemble and disassemble.
FUSION CARBON BASE KIT
K1FOFUSCB-070XXX
Regular price Sale price $1,039.00 Save $0.00HIGH PERFORMANCE - LIGHT WEIGHT
Sizes: 70 CM / 80CM
The all new Fusion ecosystem sets a new benchmark in Cabrinha's foil design & manufacturing capabilities. Performance & function is at the heart of the design process.
Each Individual part has been redesigned on both component and connection level with an option to interchange any part in the system. This effortlessly simple system puts complete customization in your hands and the new X:Series Wing options will open the door to progression on whatever craft you choose to use them with.
We proudly invite you to build your dream ride...
The Fusion Carbon kit puts performance above all else. The EPS, prepreg carbon construction gives insane stiffness in a lightweight package. It seamlessly integrates into all 9cm industry standard foil boxes. The redesigned fuselage connection platform allows the mast to tightly lock into place to withstand the vertical and horizontal forces involved in all foil disciplines.
DESIGN PROFILE
Ultimate stiffness to weight ratio and minimum drag.
MAST FEATURES
- Integrated baseplate for superior stiffness and reduced weight
- I-beam full carbon pre-preg construction.
- EPS core for superior strength to weight ratio
- Precision tapered fuse-to-mast connection for optimal rigidity
- Tapered chord for reduced drag
- 3-screw connection with threaded brass inserts
FUSELAGE FEATURES
- EPS core for superior strength to weight ratio
- Full carbon prepreg construction
- ss316 m6 inserts
- Interchangeable rear fuselage for optimal performance and easy travel
- 343mm rear fuse for superior maneuverability
- recessed stabilizer mounting surface for minimal drag
Set includes:
Mast, rear fuselage, travel bag, 5pcs m6 ss316 torx ti coated screws and torx tool.
Sold Separately:
Your choice of front and rear wing.
